OBSIDIAN-8 HEAVY LIFT

Overview
‍
The OBSIDIAN-8 HEAVY LIFT represents the pinnacle of high-capacity autonomous airframes. Engineered specifically for heavy payload delivery, large-scale sensor integration, and high-end cinema production, it bridges the gap between raw lifting performance and sub-millimeter flight precision.
‍
Featuring a coaxial octocopter layout with reinforced carbon-titanium arms and high-lumen LED status arrays, the OBSIDIAN-8 operates reliably in extreme turbulence and high-altitude industrial environments. Integrated smart power management ensures continuous flight safety with full-system redundancy.
‍
Core Innovations
‍
• Coaxial Heavy-Lift Architecture: 8 high-torque motors arranged in a coaxial layout for maximum thrust density and complete rotor failure redundancy.
• Ultra-High Payload Capacity: Engineered to transport up to 15 kg of specialized industrial equipment or cinema camera packages.
• High-Lumen Illumination Array: Integrated high-intensity LED matrix for night operations, structural illumination, and visual tracking.
• Hot-Swappable Battery System: Quad smart battery bays allowing continuous operation and zero-downtime battery swaps in the field.
• Active Airframe Stabilization: Dynamic gyro-assisted flight control system designed to neutralize wind shear and heavy-load inertia.
• Reinforced Carbon-Titanium Structure: Heavy-duty T1000 carbon fiber arms with solid titanium motor mounts for maximum structural rigidity.
‍
Technical Specifications
‍
• Dimensions: 890 mm × 890 mm × 380 mm (unfolded, excluding propellers).
• Max Takeoff Weight (MTOW): 28.5 kg.
• Max Payload Capacity: 15.0 kg.
• Max Cruise Speed: 65 km/h (Loaded).
• Operational Range: Up to 10 km direct encrypted telemetry link.
• Operating Temperature: -20°C to 50°C.
‍
Package & Deliverables
‍
• 1× OBSIDIAN-8 HEAVY LIFT Industrial Airframe.
• 1× Heavy-Duty Universal Gimbal Adapter & Quick Release Plate.
• 1× Dual-Operator Ground Control Station (GCS).
• 8× High-Capacity Industrial Smart Batteries.
• 1× 8-Bay Fast Charging Flight Case Station.
• 1× Custom Flight-Rated Transportation Trunk with Wheels.
• 1× AERO-OS Heavy Logistics Control Software License.
• 3-Year Enterprise Warranty & Express Maintenance Support.
